The Cylindrical Cell Protection Pink PET Heat Shrink Tubing is a specialized solution designed to provide comprehensive protection for cylindrical cells, particularly in lithium-ion battery applications. This tubing is crafted from high-quality Polyethylene Terephthalate (PET), a material renowned for its exceptional strength, durability, and biocompatibility. The pink coloration enhances visibility and aids in color-coding, making it easier to identify specific components within complex systems.
Electrical Insulation: The PET material offers superior electrical insulation properties, ensuring that the terminals of lithium-ion cells are well-insulated to prevent accidental short-circuiting. This is crucial in maintaining the safety and reliability of battery packs.
Mechanical Protection: The tubing provides a robust barrier against mechanical damage such as scratches and abrasions, safeguarding sensitive battery components during assembly and operation.
Thermal Management: While PET itself is not primarily used for thermal insulation, the tubing helps manage heat dissipation by maintaining a snug fit around the cells, which can aid in reducing thermal stress.
Cell Wrapping: The tubing is ideal for wrapping individual lithium cells in cylindrical designs, offering an additional layer of protection against physical impacts and leakage.
Pack Assembly: In larger battery packs, this tubing is used to bundle multiple cells together securely, ensuring a clean and organized assembly while maintaining insulation.
Material: Polyethylene Terephthalate (PET)
Color: Pink
Shrink Ratio: Typically 2:1 or 3:1, allowing for a snug fit around cylindrical cells
Temperature Range: Suitable for long-term use between -196°C and 135°C, with short-term exposure up to 200°C
Dielectric Strength: PET offers high dielectric strength, ensuring excellent electrical insulation
Biocompatibility: Compliant with ISO 10993 standards, making it suitable for applications where biocompatibility is a concern
Select the Correct Size: Choose a tubing diameter that fits snugly over the component or group of cells.
Apply Heat: Use a heat gun or other controlled heat source to evenly apply heat to the tubing. As it heats up, the tubing will shrink tightly around the battery, providing insulation and protection.
Inspect for Secure Fit: Ensure the tubing has fully shrunk around the component and has no loose spots.
